| Place of Origin: | China |
|---|---|
| Brand Name: | Kolida |
| Certification: | CE |
| Model Number: | KTS-442R10UT |
| Minimum Order Quantity: | 1 |
| Price: | negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 1-3 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000pcs per month |
| Product Name: | Total Station | Reflectorless: | 1000/ 1500m |
|---|---|---|---|
| 1 Prism: | 5000m | 3 Prism: | 8000-10000m |
| Accuracy: | 2" | Compensator: | Dual Axis Liquid-electric |
| Highlight: | Survey Total Station Reflectorless Prism,High Quality Reflectorless Prism,2′ ′ Accuracy Reflectorless Prism |
||
Measure & Setout on App,
More Productive & Smarter!
Ksurvey App allows you to import CAD basemap and stakeout it, without input point coordinates one by one. Online map can be displayed with CAD map too.
Point Stakeout and Line stakeout now is in graphic display. It brings more ease and convenience to your work.
Map & Draw on Android App,
Save Time Outdoor & Indoor!
User is allowed to draw line, polygon, circle...up to 11 kinds of graphic, while measuring target points. no need to manually draw draft map any more.
User is allowed to manage different objectives as different layers. The draft map can be saved and output in CAD format, and to be used in indoor works.
New Screen Display,
Brings You A Clearer Vision!
A series of new display chip, screen and font have been appied to 442UT. Measurement values are displayed clearer and with bigger size. The display performance under low light conditions also is better than before.
| Distance Measurement | ||
| Measurement Range1 prism: 5000m3 prism: 8000-10000mReflectorless: 1000/ 1500m | Accuracy
Prism: ±(2+2ppmx D)mmReflectorless: ±(3+2ppmx D)mm |
Measuring Time0.1 - 1s |
| Atmosphere CorrectionManual Input | Prism Constant CorrectionManual Input |
|
| Angle Measurement | ||
| Measurement MeAbsolute Encoding | Accuracy2" | Minimum Reading1"/ 5" optional |
| Compensator
Dual Axis Liquid-electricRange ±4', Accuracy 1" |
|
|
| User Interaction | ||
| Operation SystemReal Time | Color ScreenN/A | Touch ScreenN/A |
| KeyboardFull Alphanumeric keys with backlight | Trigger KeyYes | Bluetooth & wifiBluetooth |
| Internal Storage
12Mb, 96,000 points |
External Storage up to 32GB USB Flash Memory |
|
| Working Capability | ||
| ProgramCoordinate measurement, setout, area, road design... | Graphic Display N/A |
Laser Pointer & Laser PlummetYes |
| Endurance
20 hours by two batteries |
Setout Guide Light N/A |
Camera Function N/A |
